GIRACLIK® GYRATORY FLEXIBLE WITH SAFETY VALVE OF SECURITY

bandera espanola
bandera francesa

Giraclik, flexible stainless steel connection for installations of fixed and mobile gas appliances. Available in two models, male-male and male-female with safety valve and female-female.

Lengths in all models: 750 – 1000 – 1500 and 2000 mm.

Made with high quality components: corrugated AISI 316 L stainless steel inner tube, AISI 304 stainless steel mesh and PVC outer protection tube.

They are manufactured under the UNE EN 14800 standard, and UNE EN 15069, with the AENOR N certification in process.

It has a rotating elbow that allows the flexible positioning, facilitating its installation.

It avoids the torsion of the flexible in the assembly, to be able to rotate on its own axis to adapt to the curvature of its end.

It improves existing swivel elbow systems on the market. Very reinforced !!!

Ideal for the installation of kitchens, ovens, countertops, etc…

Code

5030750000
5031000000
5031500000
5032000000
5040750000
5041000000
5041500000
5042000000

Description

CFI c/v safety M-M gyratory
CFI c/v safety M-M gyratory
CFI c/v safety M-M gyratory
CFI c/v safety M-M gyratory
CFI c/v safety M-F gyratory
CFI c/v safety M-F gyratory
CFI c/v safety M-F gyratory
CFI c/v safety M-F gyratory

Thread

1/2×1/2
1/2×1/2
1/2×1/2
1/2×1/2
1/2×1/2
1/2×1/2
1/2×1/2
1/2×1/2

Length mm

750
1000
1500
2000
750
1000
1500
2000

Unit Pack.

10
10
10
10
10
10
10
10
